Addr. Parameter Function C Setting Options Default Setting Comments
674 W2S day Device, General Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Sunday day of time set winter to
summer
675 W2S hour Device, General 1 .. 24 2 hour of time set winter to
summer
676 S2W month Device, General 1 .. 12 10 month of time set
summer to winter
677 S2W week Device, General 1 .. 5 5 week of time set summer
to winter
678 S2W day Device, General Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Sunday day of time set summer
to winter
679 S2W hour Device, General 1 .. 24 3 hour of time set summer
to winter
700 GOOSE-Stop Device, General YES
NO
NO GOOSE-Stop
1101 FullScaleVolt. P.System Data
2
0.10 .. 800.00 kV 20.00 kV Measurem:FullScale-
Voltage(Equipm.rating)
1102 FullScaleCurr. P.System Data
2
10 .. 50000 A 400 A Measurem:FullScaleCur-
rent(Equipm.rating)
1103 RE/RL P.System Data
2
-0.33 .. 7.00 1.00 Zero seq. compensating
factor RE/RL
1104 XE/XL P.System Data
2
-0.33 .. 7.00 1.00 Zero seq. compensating
factor XE/XL
1105 x' P.System Data
2
1A 0.0050 ..
15.0000 Ω/mi
0.2420 Ω/mi feeder reactance per
mile: x'
5A 0.0010 ..
3.0000 Ω/mi
0.0484 Ω/mi
1106 x' P.System Data
2
1A 0.0050 ..
9.5000 Ω/km
0.1500 Ω/km feeder reactance per km:
x'
5A 0.0010 ..
1.9000 Ω/km
0.0300 Ω/km
1107 I MOTOR START P.System Data
2
1A 0.40 .. 10.00 A 2.50 A Motor Start Current
(Block 49, Start 48)
5A 2.00 .. 50.00 A 12.50 A
1108 P,Q sign P.System Data
2
not reversed
reversed
not reversed P,Q operational measured
values sign
1109 Line angle P.System Data
2
10 .. 89 ° 85 ° Line angle
1110 Line length P.System Data
2
0.1 .. 1000.0 km 100.0 km Line length in kilometer
1111 Line length P.System Data
2
0.1 .. 650.0 Miles 62.1 Miles Line length in miles
