Siemens SIPROTEC 7SJ80

Addr. Parameter Function C Setting Options Default Setting Comments
1321A 50N-1 measurem. 50/51 Overcur. Fundamental
True RMS
Fundamental 50N-1 measurement of
1322A 51N measurem. 50/51 Overcur. Fundamental
True RMS
Fundamental 51N measurement of
1501 FCT 67/67-TOC 67 Direct. O/C OFF
ON
OFF 67, 67-TOC Phase Time
Overcurrent
1502 67-2 PICKUP 67 Direct. O/C 1A 0.10 .. 35.00 A; ∞ 2.00 A 67-2 Pickup
5A 0.50 .. 175.00 A; ∞ 10.00 A
1503 67-2 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.10 sec 67-2 Time Delay
1504 67-1 PICKUP 67 Direct. O/C 1A 0.10 .. 35.00 A; ∞ 1.00 A 67-1 Pickup
5A 0.50 .. 175.00 A; ∞ 5.00 A
1505 67-1 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.50 sec 67-1Time Delay
1507 67-TOC PICKUP 67 Direct. O/C 1A 0.10 .. 4.00 A 1.00 A 67-TOC Pickup
5A 0.50 .. 20.00 A 5.00 A
1508 67 TIME DIAL 67 Direct. O/C 0.05 .. 3.20 sec; ∞ 0.50 sec 67-TOC Time Dial
1509 67 TIME DIAL 67 Direct. O/C 0.50 .. 15.00 ; ∞ 5.00 67-TOC Time Dial
1510 67-TOC Drop-out 67 Direct. O/C Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1511 67- IEC CURVE 67 Direct. O/C Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
1512 67- ANSI CURVE 67 Direct. O/C Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
1513A MANUAL CLOSE 67 Direct. O/C 67-3 instant.
67-2 instant.
67-1 instant.
67-TOC instant.
Inactive
67-2 instant. Manual Close Mode
1514A 67-2 active 67 Direct. O/C with 79 active
always
always 67-2 active
1518A 67 T DROP-OUT 67 Direct. O/C 0.00 .. 60.00 sec 0.00 sec 67 Drop-Out Time Delay
1519A ROTATION ANGLE 67 Direct. O/C -180 .. 180 ° 45 ° Rotation Angle of Refer-
ence Voltage
1520A 67-2 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67-2 measurement of
1521A 67-1 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67-1 measurement of
1522A 67-TOC MEASUR. 67 Direct. O/C Fundamental
True RMS
Fundamental 67-TOC measurement of
1523 67-2 Direction 67 Direct. O/C Forward
Reverse
Non-Directional
Forward 67-2 Direction
Functions, Settings, Information
F.2 Settings
SIPROTEC 4, 7SJ80, Manual 481
E50417-G1140-C343-A8, Edition 12.2017
