Siemens SIPROTEC 7SJ80

Addr. Parameter Function C Setting Options Default Setting Comments
1524 67-1 Direction 67 Direct. O/C Forward
Reverse
Non-Directional
Forward 67-1 Direction
1525 67-TOC Direct. 67 Direct. O/C Forward
Reverse
Non-Directional
Forward 67-TOC Direction
1526 67-3 Direction 67 Direct. O/C Forward
Reverse
Non-Directional
Forward 67-3 Direction
1527A 67-3 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67-3 measurement of
1528 67-3 PICKUP 67 Direct. O/C 1A 1.00 .. 35.00 A; ∞ ∞ A 67-3 Pickup
5A 5.00 .. 175.00 A; ∞ ∞ A
1529 67-3 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.00 sec 67-3 Time Delay
1530 67 67 Direct. O/C 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
67
1531 MofPU Res T/Tp 67 Direct. O/C 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
Multiple of Pickup <->
T/Tp
1532A 67-3 active 67 Direct. O/C always
with 79 active
always 67-3 active
1601 FCT 67N/67N-TOC 67 Direct. O/C OFF
ON
OFF 67N, 67N-TOC Ground
Time Overcurrent
1602 67N-2 PICKUP 67 Direct. O/C 1A 0.05 .. 35.00 A; ∞ 0.50 A 67N-2 Pickup
5A 0.25 .. 175.00 A; ∞ 2.50 A
1603 67N-2 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.10 sec 67N-2 Time Delay
1604 67N-1 PICKUP 67 Direct. O/C 1A 0.05 .. 35.00 A; ∞ 0.20 A 67N-1 Pickup
5A 0.25 .. 175.00 A; ∞ 1.00 A
1605 67N-1 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.50 sec 67N-1 Time Delay
1607 67N-TOC PICKUP 67 Direct. O/C 1A 0.05 .. 4.00 A 0.20 A 67N-TOC Pickup
5A 0.25 .. 20.00 A 1.00 A
1608 67N-TOC T-DIAL 67 Direct. O/C 0.05 .. 3.20 sec; ∞ 0.20 sec 67N-TOC Time Dial
1609 67N-TOC T-DIAL 67 Direct. O/C 0.50 .. 15.00 ; ∞ 5.00 67N-TOC Time Dial
1610 67N-TOC DropOut 67 Direct. O/C Instantaneous
Disk Emulation
Disk Emulation Drop-Out Characteristic
1611 67N-TOC IEC 67 Direct. O/C Normal Inverse
Very Inverse
Extremely Inv.
Long Inverse
Normal Inverse IEC Curve
1612 67N-TOC ANSI 67 Direct. O/C Very Inverse
Inverse
Short Inverse
Long Inverse
Moderately Inv.
Extremely Inv.
Definite Inv.
Very Inverse ANSI Curve
Functions, Settings, Information
F.2 Settings
482 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
