Addr. Parameter Function C Setting Options Default Setting Comments
1613A MANUAL CLOSE 67 Direct. O/C 67N-3 instant.
67N-2 instant.
67N-1 instant.
67N-TOC instant
Inactive
67N-2 instant. Manual Close Mode
1614A 67N-2 active 67 Direct. O/C always
with 79 active
always 67N-2 active
1617 67N POLARIZAT. 67 Direct. O/C with VN and IN
with V2 and I2
with VN and IN Ground Polarization
1618A 67N T DROP-OUT 67 Direct. O/C 0.00 .. 60.00 sec 0.00 sec 67N Drop-Out Time Delay
1619A ROTATION ANGLE 67 Direct. O/C -180 .. 180 ° -45 ° Rotation Angle of Refer-
ence Voltage
1620A 67N-2 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67N-2 measurement of
1621A 67N-1 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67N-1 measurement of
1622A 67N-TOC MEASUR. 67 Direct. O/C Fundamental
True RMS
Fundamental 67N-TOC measurement
of
1623 67N-2 Direction 67 Direct. O/C Forward
Reverse
Non-Directional
Forward 67N-2 Direction
1624 67N-1 Direction 67 Direct. O/C Forward
Reverse
Non-Directional
Forward 67N-1 Direction
1625 67N-TOC Direct. 67 Direct. O/C Forward
Reverse
Non-Directional
Forward 67N-TOC Direction
1626 67N-3 Direction 67 Direct. O/C Forward
Reverse
Non-Directional
Forward 67N-3 Direction
1627A 67N-3 MEASUREM. 67 Direct. O/C Fundamental
True RMS
Fundamental 67N-3 measurement of
1628 67N-3 PICKUP 67 Direct. O/C 0.50 .. 35.00 A; ∞ ∞ A 67N-3 Pickup
1629 67N-3 DELAY 67 Direct. O/C 0.00 .. 60.00 sec; ∞ 0.00 sec 67N-3 Time Delay
1630 M.of PU TD 67 Direct. O/C 1.00 .. 20.00 I/Ip; ∞
0.01 .. 999.00 TD
Multiples of PU Time-Dial
1631 I/IEp Rf T/TEp 67 Direct. O/C 0.05 .. 0.95 I/Ip; ∞
0.01 .. 999.00 TD
67N TOC
1632A 67N-3 active 67 Direct. O/C always
with 79 active
always 67N-3 active
1701 COLDLOAD PICKUP ColdLoadPickup OFF
ON
OFF Cold-Load-Pickup Func-
tion
1702 Start Condition ColdLoadPickup No Current
Breaker Contact
79 ready
No Current Start Condition
1703 CB Open Time ColdLoadPickup 0 .. 21600 sec 3600 sec Circuit Breaker OPEN
Time
1704 Active Time ColdLoadPickup 0 .. 21600 sec 3600 sec Active Time
