Siemens SIPROTEC 7SJ80

Addr. Parameter Function C Setting Options Default Setting Comments
7116 Max. DEAD EXT. 79M Auto Recl. 0.50 .. 1800.00 sec;
∞
100.00 sec Maximum dead time
extension
7117 T-ACTION 79M Auto Recl. 0.01 .. 320.00 sec;
∞
∞ sec Action time
7118 T DEAD DELAY 79M Auto Recl. 0.0 .. 1800.0 sec; ∞ 1.0 sec Maximum Time Delay of
Dead-Time Start
7127 DEADTIME 1: PH 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 1: Phase Fault
7128 DEADTIME 1: G 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 1: Ground
Fault
7129 DEADTIME 2: PH 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 2: Phase Fault
7130 DEADTIME 2: G 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 2: Ground
Fault
7131 DEADTIME 3: PH 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 3: Phase Fault
7132 DEADTIME 3: G 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 3: Ground
Fault
7133 DEADTIME 4: PH 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 4: Phase Fault
7134 DEADTIME 4: G 79M Auto Recl. 0.01 .. 320.00 sec 0.50 sec Dead Time 4: Ground
Fault
7135 # OF RECL. GND 79M Auto Recl. 0 .. 9 1 Number of Reclosing
Cycles Ground
7136 # OF RECL. PH 79M Auto Recl. 0 .. 9 1 Number of Reclosing
Cycles Phase
7137 Cmd.via control 79M Auto Recl. (Einstellmöglich-
keiten anwendung-
sabhängig)
none Close command via
control device
7138 Internal SYNC 79M Auto Recl. (Einstellmöglich-
keiten anwendung-
sabhängig)
none Internal 25 synchronisa-
tion
7139 External SYNC 79M Auto Recl. YES
NO
NO External 25 synchronisa-
tion
7140 ZONE SEQ.COORD. 79M Auto Recl. OFF
ON
OFF ZSC - Zone sequence
coordination
7150 50-1 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50-1
7151 50N-1 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50N-1
7152 50-2 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50-2
7153 50N-2 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50N-2
7154 51 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 51
7155 51N 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 51N
Functions, Settings, Information
F.2 Settings
494 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
