Addr. Parameter Function C Setting Options Default Setting Comments
7156 67-1 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 67-1
7157 67N-1 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 67N-1
7158 67-2 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 67-2
7159 67N-2 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 67N-2
7160 67 TOC 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 67 TOC
7161 67N TOC 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 67N TOC
7162 sens Ground Flt 79M Auto Recl. No influence
Starts 79
Stops 79
No influence (Sensitive) Ground Fault
7163 46 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 46
7164 BINARY INPUT 79M Auto Recl. No influence
Starts 79
Stops 79
No influence Binary Input
7165 3Pol.PICKUP BLK 79M Auto Recl. YES
NO
NO 3 Pole Pickup blocks 79
7166 50-3 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50-3
7167 50N-3 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 50N-3
7168 67-3 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 67-3
7169 67N-3 79M Auto Recl. No influence
Starts 79
Stops 79
No influence 67N-3
7200 bef.1.Cy:50-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50-1
7201 bef.1.Cy:50N-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50N-1
