Addr. Parameter Function C Setting Options Default Setting Comments
7234 bef.3.Cy:67 TOC 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: 67 TOC
7235 bef.3.Cy:67NTOC 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: 67N TOC
7236 bef.4.Cy:50-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50-1
7237 bef.4.Cy:50N-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50N-1
7238 bef.4.Cy:50-2 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50-2
7239 bef.4.Cy:50N-2 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50N-2
7240 bef.4.Cy:51 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 51
7241 bef.4.Cy:51N 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 51N
7242 bef.4.Cy:67-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 67-1
7243 bef.4.Cy:67N-1 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 67N-1
7244 bef.4.Cy:67-2 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 67-2
7245 bef.4.Cy:67N-2 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 67N-2
7246 bef.4.Cy:67 TOC 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 67 TOC
7247 bef.4.Cy:67NTOC 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 67N TOC
7248 bef.1.Cy:50-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50-3
7249 bef.1.Cy:50N-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50N-3
Functions, Settings, Information
F.2 Settings
498 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
