Addr. Parameter Function C Setting Options Default Setting Comments
7250 bef.2.Cy:50-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50-3
7251 bef.2.Cy:50N-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50N-3
7252 bef.3.Cy:50-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: 50-3
7253 bef.3.Cy:50N-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: 50N-3
7254 bef.4.Cy:50-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50-3
7255 bef.4.Cy:50N-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50N-3
7256 bef.1.Cy:67-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 67-3
7257 bef.1.Cy:67N-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: IE>>>
directional
7258 bef.2.Cy:67-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 67-3
7259 bef.2.Cy:67N-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: IE>>>
directional
7260 bef.3.Cy:67-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: 67-3
7261 bef.3.Cy:67N-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 3. Cycle: IE>>>
directional
7262 bef.4.Cy:67-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 67-3
7263 bef.4.Cy:67N-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 67N-3
8001 START Fault Locator Pickup
TRIP
Pickup Start fault locator with
8101 MEASURE. SUPERV Meas-
urem.Superv
OFF
ON
ON Measurement Supervision
8102 BALANCE V-LIMIT Meas-
urem.Superv
10 .. 100 V 50 V Voltage Threshold for
Balance Monitoring
Functions, Settings, Information
F.2 Settings
SIPROTEC 4, 7SJ80, Manual 499
E50417-G1140-C343-A8, Edition 12.2017
