Siemens SIPROTEC 7SJ80 User Manual

No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
511 Relay GENERAL TRIP
command (Relay TRIP)
P.System
Data 2
OUT ON m LED BO 15
0
16
1
2 Yes
533 Primary fault current Ia (Ia
=)
P.System
Data 2
VI ON
OFF
15
0
17
7
4 No
534 Primary fault current Ib
(Ib =)
P.System
Data 2
VI ON
OFF
15
0
17
8
4 No
535 Primary fault current Ic (Ic
=)
P.System
Data 2
VI ON
OFF
15
0
17
9
4 No
545 Time from Pickup to drop
out (PU Time)
Device,
General
VI
546 Time from Pickup to TRIP
(TRIP Time)
Device,
General
VI
561 Manual close signal
detected
(Man.Clos.Detect)
P.System
Data 2
OUT On
Of
f
* * LED BO
916 Increment of active
energy (WpΔ=)
Energy -
917 Increment of reactive
energy (WqΔ=)
Energy -
1020 Counter of operating
hours (Op.Hours=)
Statistics VI
1021 Accumulation of inter-
rupted current Ph A (Σ Ia
=)
Statistics VI
1022 Accumulation of inter-
rupted current Ph B (Σ Ib
=)
Statistics VI
1023 Accumulation of inter-
rupted current Ph C (Σ Ic
=)
Statistics VI
1106 >Start Fault Locator
(>Start Flt. Loc)
Fault
Locator
SP On * * LED BI BO 15
1
6 1 Yes
1114 Flt Locator: primary
RESISTANCE (Rpri =)
Fault
Locator
VI ON
OFF
15
1
14 4 No
1115 Flt Locator: primary REAC-
TANCE (Xpri =)
Fault
Locator
VI ON
OFF
15
1
15 4 No
1117 Flt Locator: secondary
RESISTANCE (Rsec =)
Fault
Locator
VI ON
OFF
15
1
17 4 No
1118 Flt Locator: secondary
REACTANCE (Xsec =)
Fault
Locator
VI ON
OFF
15
1
18 4 No
1119 Flt Locator: Distance to
fault (dist =)
Fault
Locator
VI ON
OFF
15
1
19 4 No
Functions, Settings, Information
F.3 Information List
514 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
