No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
1840 Phase A inrush detection
(PhA InrushDet)
50/51
Overcur.
OUT * On
Off
* LED BO 60 10
1
2 Yes
1841 Phase B inrush detection
(PhB InrushDet)
50/51
Overcur.
OUT * On
Off
* LED BO 60 10
2
2 Yes
1842 Phase C inrush detection
(PhC InrushDet)
50/51
Overcur.
OUT * On
Off
* LED BO 60 10
3
2 Yes
1843 Cross blk: PhX blocked
PhY (INRUSH X-BLK)
50/51
Overcur.
OUT * On
Off
* LED BO 60 10
4
2 Yes
1851 50-1 BLOCKED (50-1
BLOCKED)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 10
5
1 Yes
1852 50-2 BLOCKED (50-2
BLOCKED)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 10
6
1 Yes
1853 50N-1 BLOCKED (50N-1
BLOCKED)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 10
7
1 Yes
1854 50N-2 BLOCKED (50N-2
BLOCKED)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 10
8
1 Yes
1855 51 BLOCKED (51
BLOCKED)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 10
9
1 Yes
1856 51N BLOCKED (51N
BLOCKED)
50/51
Overcur.
OUT On
Of
f
On
Off
* LED BO 60 11
0
1 Yes
1866 51 Disk emulation Pickup
(51 Disk Pickup)
50/51
Overcur.
OUT * * * LED BO
1867 51N Disk emulation
picked up (51N Disk
Pickup)
50/51
Overcur.
OUT * * * LED BO
1994 Cold-Load-Pickup
switched OFF (CLP OFF)
ColdLoad-
Pickup
OUT On
Of
f
* * LED BO 60 24
4
1 Yes
1995 Cold-Load-Pickup is
BLOCKED (CLP BLOCKED)
ColdLoad-
Pickup
OUT On
Of
f
On
Off
* LED BO 60 24
5
1 Yes
1996 Cold-Load-Pickup is
RUNNING (CLP running)
ColdLoad-
Pickup
OUT On
Of
f
* * LED BO 60 24
6
1 Yes
1997 Dynamic settings are
ACTIVE (Dyn set. ACTIVE)
ColdLoad-
Pickup
OUT On
Of
f
* * LED BO 60 24
7
1 Yes
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SJ80, Manual 521
E50417-G1140-C343-A8, Edition 12.2017
