Siemens SIPROTEC 7SJ80 User Manual

No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
2603 67N-3 TRIP (67N-3 TRIP) 67 Direct.
O/C
OUT * On * LED BO
2604 >BLOCK 67/67-TOC (>BLK
67/67-TOC)
67 Direct.
O/C
SP * * * LED BI BO
2605 67N-3 is BLOCKED (67N-3
BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO
2606 67-3 is BLOCKED (67-3
BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO
2614 >BLOCK 67N/67N-TOC
(>BLK 67N/67NTOC)
67 Direct.
O/C
SP * * * LED BI BO
2615 >BLOCK 67-2 (>BLOCK
67-2)
67 Direct.
O/C
SP * * * LED BI BO 63 73 1 Yes
2616 >BLOCK 67N-2 (>BLOCK
67N-2)
67 Direct.
O/C
SP * * * LED BI BO 63 74 1 Yes
2617 >BLOCK 67-3 (>BLOCK
67-3)
67 Direct.
O/C
SP * * * LED BI BO
2618 >BLOCK 67N-3 (>BLOCK
67N-3)
67 Direct.
O/C
SP * * * LED BI BO
2621 >BLOCK 67-1 (>BLOCK
67-1)
67 Direct.
O/C
SP * * * LED BI BO 63 1 1 Yes
2622 >BLOCK 67-TOC (>BLOCK
67-TOC)
67 Direct.
O/C
SP * * * LED BI BO 63 2 1 Yes
2623 >BLOCK 67N-1 (>BLOCK
67N-1)
67 Direct.
O/C
SP * * * LED BI BO 63 3 1 Yes
2624 >BLOCK 67N-TOC
(>BLOCK 67N-TOC)
67 Direct.
O/C
SP * * * LED BI BO 63 4 1 Yes
2628 Phase A forward (Phase A
forward)
67 Direct.
O/C
OUT On * * LED BO 63 81 1 Yes
2629 Phase B forward (Phase B
forward)
67 Direct.
O/C
OUT On * * LED BO 63 82 1 Yes
2630 Phase C forward (Phase C
forward)
67 Direct.
O/C
OUT On * * LED BO 63 83 1 Yes
2632 Phase A reverse (Phase A
reverse)
67 Direct.
O/C
OUT On * * LED BO 63 84 1 Yes
2633 Phase B reverse (Phase B
reverse)
67 Direct.
O/C
OUT On * * LED BO 63 85 1 Yes
2634 Phase C reverse (Phase C
reverse)
67 Direct.
O/C
OUT On * * LED BO 63 86 1 Yes
2635 Ground forward (Ground
forward)
67 Direct.
O/C
OUT On * * LED BO 63 87 1 Yes
Functions, Settings, Information
F.3 Information List
522 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
