No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
2636 Ground reverse (Ground
reverse)
67 Direct.
O/C
OUT On * * LED BO 63 88 1 Yes
2637 67-1 is BLOCKED (67-1
BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO 63 91 1 Yes
2642 67-2 picked up (67-2
picked up)
67 Direct.
O/C
OUT * On
Off
* LED BO 63 67 2 Yes
2646 67N-2 picked up (67N-2
picked up)
67 Direct.
O/C
OUT * On
Off
* LED BO 63 62 2 Yes
2647 67-2 Time Out (67-2 Time
Out)
67 Direct.
O/C
OUT * * * LED BO 63 71 2 Yes
2648 67N-2 Time Out (67N-2
Time Out)
67 Direct.
O/C
OUT * * * LED BO 63 63 2 Yes
2649 67-2 TRIP (67-2 TRIP) 67 Direct.
O/C
OUT * On m LED BO 63 72 2 Yes
2651 67/67-TOC switched OFF
(67/67-TOC OFF)
67 Direct.
O/C
OUT On
Of
f
* * LED BO 63 10 1 Yes
2652 67/67-TOC is BLOCKED
(67 BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO 63 11 1 Yes
2653 67/67-TOC is ACTIVE (67
ACTIVE)
67 Direct.
O/C
OUT On
Of
f
* * LED BO 63 12 1 Yes
2655 67-2 is BLOCKED (67-2
BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO 63 92 1 Yes
2656 67N/67N-TOC switched
OFF (67N OFF)
67 Direct.
O/C
OUT On
Of
f
* * LED BO 63 13 1 Yes
2657 67N/67N-TOC is BLOCKED
(67N BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO 63 14 1 Yes
2658 67N/67N-TOC is ACTIVE
(67N ACTIVE)
67 Direct.
O/C
OUT On
Of
f
* * LED BO 63 15 1 Yes
2659 67N-1 is BLOCKED (67N-1
BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO 63 93 1 Yes
2660 67-1 picked up (67-1
picked up)
67 Direct.
O/C
OUT * On
Off
* LED BO 63 20 2 Yes
2664 67-1 Time Out (67-1 Time
Out)
67 Direct.
O/C
OUT * * * LED BO 63 24 2 Yes
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SJ80, Manual 523
E50417-G1140-C343-A8, Edition 12.2017
