No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
2665 67-1 TRIP (67-1 TRIP) 67 Direct.
O/C
OUT * On m LED BO 63 25 2 Yes
2668 67N-2 is BLOCKED (67N-2
BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO 63 94 1 Yes
2669 67-TOC is BLOCKED (67-
TOC BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO 63 95 1 Yes
2670 67-TOC picked up (67-
TOC pickedup)
67 Direct.
O/C
OUT * On
Off
* LED BO 63 30 2 Yes
2674 67-TOC Time Out (67-
TOC Time Out)
67 Direct.
O/C
OUT * * * LED BO 63 34 2 Yes
2675 67-TOC TRIP (67-TOC
TRIP)
67 Direct.
O/C
OUT * On m LED BO 63 35 2 Yes
2676 67-TOC disk emulation is
ACTIVE (67-TOC DiskPU)
67 Direct.
O/C
OUT * * * LED BO
2677 67N-TOC is BLOCKED
(67N-TOC BLOCKED)
67 Direct.
O/C
OUT On
Of
f
On
Off
* LED BO 63 96 1 Yes
2678 67-3 TRIP (67-3 TRIP) 67 Direct.
O/C
OUT * On * LED BO
2679 67N-2 TRIP (67N-2 TRIP) 67 Direct.
O/C
OUT * On m LED BO 63 64 2 Yes
2681 67N-1 picked up (67N-1
picked up)
67 Direct.
O/C
OUT * On
Off
* LED BO 63 41 2 Yes
2682 67N-1 Time Out (67N-1
Time Out)
67 Direct.
O/C
OUT * * * LED BO 63 42 2 Yes
2683 67N-1 TRIP (67N-1 TRIP) 67 Direct.
O/C
OUT * On m LED BO 63 43 2 Yes
2684 67N-TOC picked up (67N-
TOCPickedup)
67 Direct.
O/C
OUT * On
Off
* LED BO 63 44 2 Yes
2685 67N-TOC Time Out (67N-
TOC TimeOut)
67 Direct.
O/C
OUT * * * LED BO 63 45 2 Yes
2686 67N-TOC TRIP (67N-TOC
TRIP)
67 Direct.
O/C
OUT * On m LED BO 63 46 2 Yes
2687 67N-TOC disk emulation
is ACTIVE (67N-TOC Disk
PU)
67 Direct.
O/C
OUT * * * LED BO
2691 67/67N picked up
(67/67N pickedup)
67 Direct.
O/C
OUT * On
Off
m LED BO 63 50 2 Yes
2692 67/67-TOC Phase A
picked up (67 A picked
up)
67 Direct.
O/C
OUT * On
Off
* LED BO 63 51 2 Yes
Functions, Settings, Information
F.3 Information List
524 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
