No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
2890 79 2nd cycle zone exten-
sion release (79 2.CycZo-
neRel)
79M Auto
Recl.
OUT * * * LED BO
2891 79 3rd cycle zone exten-
sion release (79 3.CycZo-
neRel)
79M Auto
Recl.
OUT * * * LED BO
2892 79 4th cycle zone exten-
sion release (79 4.CycZo-
neRel)
79M Auto
Recl.
OUT * * * LED BO
2896 No. of 1st AR-cycle CLOSE
commands,3pole (79
#Close1./3p=)
Statistics VI
2898 No. of higher AR-cycle
CLOSE commands,3p (79
#Close2./3p=)
Statistics VI
2899 79: Close request to
Control Function (79
CloseRequest)
79M Auto
Recl.
OUT * On * LED BO
4601 >52-a contact (OPEN, if
bkr is open) (>52-a)
P.System
Data 2
SP On
Of
f
* * LED BI BO
4602 >52-b contact (OPEN, if
bkr is closed) (>52-b)
P.System
Data 2
SP On
Of
f
* * LED BI BO
5143 >BLOCK 46 (>BLOCK 46) 46 Negative
Seq
SP * * * LED BI BO 70 12
6
1 Yes
5145 >Reverse Phase Rotation
(>Reverse Rot.)
P.System
Data 1
SP On
Of
f
* * LED BI BO
5147 Phase rotation ABC (Rota-
tion ABC)
P.System
Data 1
OUT On
Of
f
* * LED BO 70 12
8
1 Yes
5148 Phase rotation ACB (Rota-
tion ACB)
P.System
Data 1
OUT On
Of
f
* * LED BO 70 12
9
1 Yes
5151 46 switched OFF (46 OFF) 46 Negative
Seq
OUT On
Of
f
* * LED BO 70 13
1
1 Yes
5152 46 is BLOCKED (46
BLOCKED)
46 Negative
Seq
OUT On
Of
f
On
Off
* LED BO 70 13
2
1 Yes
5153 46 is ACTIVE (46 ACTIVE) 46 Negative
Seq
OUT On
Of
f
* * LED BO 70 13
3
1 Yes
Functions, Settings, Information
F.3 Information List
528 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017
