Siemens SIPROTEC 7SJ80 User Manual

No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
884 Power Factor Maximum (PF Max=) Min/Max meter - - - - - -
885 Power Factor Minimum (PF Min=) Min/Max meter - - - - - -
888 Pulsed Energy Wp (active)
(Wp(puls))
Energy 133 55 No 205 - CFC
889 Pulsed Energy Wq (reactive)
(Wq(puls))
Energy 133 56 No 205 - CFC
901 Power Factor (PF =) Measurement 134 157 No 9 14 CFC
924 Wp Forward (WpForward) Energy 133 51 No 205 - CFC
925 Wq Forward (WqForward) Energy 133 52 No 205 - CFC
928 Wp Reverse (WpReverse) Energy 133 53 No 205 - CFC
929 Wq Reverse (WqReverse) Energy 133 54 No 205 - CFC
963 I A demand (Ia dmd=) Demand meter - - - - - CFC
964 I B demand (Ib dmd=) Demand meter - - - - - CFC
965 I C demand (Ic dmd=) Demand meter - - - - - CFC
1058 Overload Meter Max (Θ/
ΘTrpMax=)
Min/Max meter - - - - - CFC
1059 Overload Meter Min (Θ/ΘTrpMin=) Min/Max meter - - - - - CFC
16004 Threshold Sum Current Exponen-
tiation (ΣI^x>)
SetPoint(Stat) - - - - - CFC
16009 Lower Threshold of CB Residual
Endurance (Resid.Endu. <)
SetPoint(Stat) - - - - - CFC
16017 Threshold Sum Squared Current
Integral (ΣI^2t>)
SetPoint(Stat) - - - - - CFC
16031 Angle between 3Vo and INsens.
(φ(3Vo,INs) =)
Measurement - - - - - CFC
18473 Va-b RMS(10 minute RMS value)
(Va-b RMS=)
Measurement - - - - - CFC
18474 Vb-c RMS(10 minute RMS value)
(Vb-c RMS=)
Measurement - - - - - CFC
18475 Vc-a RMS(10 minute RMS value)
(Vc-a RMS=)
Measurement - - - - - CFC
30701 Pa (active power, phase A) (Pa =) Measurement - - - - - CFC
30702 Pb (active power, phase B) (Pb =) Measurement - - - - - CFC
30703 Pc (active power, phase C) (Pc =) Measurement - - - - - CFC
30704 Qa (reactive power, phase A) (Qa
=)
Measurement - - - - - CFC
30705 Qb (reactive power, phase B) (Qb
=)
Measurement - - - - - CFC
30706 Qc (reactive power, phase C) (Qc
=)
Measurement - - - - - CFC
30707 Power Factor, phase A (PFa =) Measurement - - - - - CFC
30708 Power Factor, phase B (PFb =) Measurement - - - - - CFC
Functions, Settings, Information
F.5 Measured Values
544 SIPROTEC 4, 7SJ80, Manual
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
