Siemens SIPROTEC 7SJ80 User Manual

No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
30709 Power Factor, phase C (PFc =) Measurement - - - - - CFC
30800 Voltage VX (VX =) Measurement - - - - - CFC
30801 Voltage phase-neutral (Vph-n =) Measurement - - - - - CFC
Functions, Settings, Information
F.5 Measured Values
SIPROTEC 4, 7SJ80, Manual 545
E50417-G1140-C343-A8, Edition 12.2017

Siemens SIPROTEC 7SJ80 Specifications

General

Rated Frequency	50/60 Hz
Rated Current	1 A / 5 A
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to +70°C
Current Transformer Inputs	4
Application	Protection of feeders, motors, transformers, and generators
Rated Voltage	100-240 V AC/DC
Communication Protocols	IEC 61850, Modbus, DNP3, IEC 60870-5-103
Display	Graphical LCD
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault
Communication Interfaces	Ethernet, RS485
Housing	Plastic
Weight	Approx. 1.5 kg
