DME Wipe Settings for Independent Key Transitions
Chapter 6 DME Wipes
Setting the DME wipe pattern size (Size)
For applicable pattern numbers, see page 143.
1 In the Key 1 DME Wipe Adjust menu, press [Size],
turning it on.
2 Set the following parameter.
a) The effect size when [Size] is off is taken as 100.00%.
Cropping a key DME wipe
1 In the <Crop Mode> group of the Key1 DME Wipe
Adjust menu, press [Crop], turning it on.
2 Set the following parameters.
To crop to 4:3 in 16:9 mode
In the <Crop Mode> group, press [4:3 Crop], turning it on.
To set the operation for DME wipe crop transition
execution
1 In the <Crop Mode> group of the Key1 DME Wipe
Adjust menu, press [Crop], turning it on.
2 In the <Crop Mode> group, press [Crop] or [4:3 Crop]
(to crop to 4:3 in 16:9 mode), turning it on.
3 In the <Crop Mode> group, press [Remove From
Begin].
The Remove From Begin menu appears.
For subsequent operations, see step 5 of “To set the
action when a DME wipe crop transition is executed”
(page 148).
To set the timing of transition completion
1 In the <Crop Mode> group of the Key1 DME Wipe
Adjust menu, press [Crop], turning it on.
2 In the <Crop Mode> group, press [Remove From
Begin].
For subsequent operations, see “Setting the timing of
transition completion” (page 149).
Applying a border to a key DME wipe
In the <Edge> group of the Key1 DME Wipe Adjust menu,
press [Border], turning it on.
For subsequent operations, use the same process as in step
4 of “Modifying the DME wipe pattern edge” (page 146).
Knob Parameter Adjustment Setting values
1Size Set size of
effect
0.00 to 200.00
a)
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 H Crop the left
and right of the
Left value shown
2 V Crop the top
and bottom of
the image
Top value shown
3 All Crop the top,
bottom, left,
and right of the
Left value shown
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Cropping of the
top of the
–100.00 to
+100.00
2 Left Cropping of the
left of the
–100.00 to
+100.00
3 Right Cropping of the
right of the
–100.00 to
+100.00
4 Bottom Cropping of the
bottom of the
–100.00 to
+100.00
