M/E Configuration Switching
Chapter 10 Special Functions
a) No restriction is applied to P/P. Thus, both utility buses 1 and 2 can be used
for P/P.
Utility bus M/E-1 Since only one utility bus is available,
utility 1 bus is used instead of utility 2
bus in the following functions.
a)
Wipe border
Preset color mix
Backgrounds of DME wipes
M/E-1, P/P Since only one utility bus is available,
utility 1 bus is used instead of utility 2
bus in the following functions.
Wipe border
Preset color mix
Backgrounds of DME wipes
M/E-2 Since only one utility bus is available,
you cannot select the following
functions.
Key border
•Sub mask
Preset color mix
Wipe border
M/E-2, M/E-3 Since only one utility bus is available,
you cannot select the following
functions.
Key border
Sub mask
Preset color mix
Wipe border
M/E-2 If you select a DME wipe which uses
a utility bus for a background image,
a color matte signal is used instead
of a utility bus signal.
M/E-2, M/E-3 If you select a DME wipe which uses
a utility bus for a background image,
a color matte signal is used instead
of a utility bus signal.
Side flags M/E-2 Side flags cannot be used. M/E-2, M/E-3 Side flags cannot be used.
DME All M/Es and
P/P
For PGM/PST, the same restrictions
as those for 2M/E apply. For M/E1
and M/E-2, the same restrictions as
those for 4M/E mode apply.
All M/Es and
P/P
For the dedicated interface, DME
can be used in only one place for
each M/E.
For the SDI interface, DME wipes
and processed keys cannot be
used.
Only one-channel mode patterns
can be selected for DME wipes.
Classification 3M/E mode 4M/E mode
