Sony MVS-7000X - Page 244

244
Applying Special Effects (Edge Effects)
Chapter 11 DME Operations
The valid ranges of the parameter values depend on the
combination of signal format (SD/HD) and aspect
ratio (4:3/16:9) selected in the system, as follows.
4:3 mode
16:9 mode
Adjusting the position of art edges
1 In the Art Edge menu, press [Edge Position], turning it
on.
2 Adjust the following parameters.
The valid ranges of the parameter values depend on the
combination of signal format (SD/HD) and aspect
ratio (4:3/16:9) selected in the system, as follows.
4:3 mode
16:9 mode
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 H Simultane-
ously adjust
width of left
and right
edges
Value of Left shown
2 V Simultane-
ously adjust
width of top
and bottom
edges
Value of Top shown
3 All Simultane-
ously adjust
width of all
four edges
Value of Left shown
5 Density Density of
edges
0.00 to 100.00
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Width of top
edge
0.00 to 6.00 (SD)
0.00 to 18.00 (HD)
2 Left Width of left
edge
0.00 to 8.00 (SD)
0.00 to 24.00 (HD)
3 Right Width of right
edge
0.00 to 8.00 (SD)
0.00 to 24.00 (HD)
4 Bottom Width of
bottom edge
0.00 to 6.00 (SD)
0.00 to 18.00 (HD)
5 Density Density of
edges
0.00 to 100.00
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 H Simultane-
ously adjust
width of left
and right
edges
Value of Left shown
2 V Simultane-
ously adjust
width of top
and bottom
edges
Value of Top shown
3 All Simultane-
ously adjust
width of all
four edges
Value of Left shown
5 Density Density of
edges
0.00 to 100.00
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Top Width of top
edge
0.00 to 4.50 (SD)
0.00 to 18.00 (HD)
2 Left Width of left
edge
0.00 to 8.00 (SD)
0.00 to 32.00 (HD)
3 Right Width of right
edge
0.00 to 8.00 (SD)
0.00 to 32.00 (HD)
4 Bottom Width of
bottom edge
0.00 to 6.00 (SD)
0.00 to 18.00 (HD)
5 Density Density of
edges
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Top Position of
top edge
–3.00 to +3.00 (SD)
–9.00 to +9.00 (HD)
2 Left Position of
left edge
–4.00 to +4.00 (SD)
–12.00 to +12.00
(HD)
3 Right Position of
right edge
–4.00 to +4.00 (SD)
–12.00 to +12.00
(HD)
4 Bottom Position of
bottom edge
–3.00 to +3.00 (SD)
–9.00 to +9.00 (HD)
5 All Adjust the
position of all
four edges
Value of H shown
Knob Parameter Adjustment Setting values
1 Top Position of
top edge
–2.25 to +2.25 (SD)
–9.00 to +9.00 (HD)
2 Left Position of
left edge
–4.00 to +4.00 (SD)
–16.00 to +16.00
(HD)
3 Right Position of
right edge
–4.00 to +4.00 (SD)
–16.00 to +16.00
(HD)
4 Bottom Position of
bottom edge
–2.25 to +2.25 (SD)
–9.00 to +9.00 (HD)
5 All Adjust the
position of all
four edges
Value of H shown
