Applying Special Effects (Edge Effects)
Chapter 11 DME Operations
4:3 mode
16:9 mode
Radial Gradation and Radial Rainbow parameters
Rainbow Gradation parameters
The valid ranges of the parameter values depend on the
combination of signal format (SD/HD) and aspect
ratio (4:3/16:9) selected in the system, as follows.
•4:3 mode
• 16:9 mode
3 When Gradation Matte or Rainbow Matte is selected,
set modifiers as required.
When turning [Angle] on in the <Rotation> group
and slanting the pattern
a) –1.00 is one rotation in counterclockwise direction. +1.00 is one
rotation in clockwise direction. 0.00 is no rotation.
When turning [Speed] on in the <Rotation> group
and rotating the pattern at a specified speed
a) –100.00 is four rotations per second in counterclockwise direction.
+100.00 is four rotations per second in clockwise direction. 0.00 is
no rotation.
Knob Parameter Adjustment Setting values
1 H Position of
gradation
border in
horizontal
direction
–8.00 to +8.00 (SD)
–24.00 to +24.00
(HD)
2 V Position of
gradation
border in
vertical
direction
–6.00 to +6.00 (SD)
–18.00 to +18.00
(HD)
3 Soft Softness of
gradation
border
region
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 H Position of
gradation
border in
horizontal
direction
–8.00 to +8.00 (SD)
–32.00 to +32.00
(HD)
2 V Position of
gradation
border in
vertical
direction
–4.50 to +4.50 (SD)
–18.00 to +18.00
(HD)
3 Soft Softness of
gradation
border
region
0.00 to 100.00
Knob Parameter Adjustment Setting values
3 Soft Softness of
gradation
border
region
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 H Position of
gradation
border in
horizontal
direction
–8.00 to +8.00 (SD)
–24.00 to +24.00
(HD)
2 V Position of
gradation
border in
vertical
direction
–6.00 to +6.00 (SD)
–18.00 to +18.00
(HD)
3 RBW Soft Softness of
rainbow
border
region
0.00 to 100.00
4 GRD Soft Softness of
gradation
border
region
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 H Position of
gradation
border in
horizontal
direction
–8.00 to +8.00 (SD)
–32.00 to +32.00
(HD)
2 V Position of
gradation
border in
vertical
direction
–4.50 to +4.50 (SD)
–18.00 to +18.00
(HD)
3 RBW Soft Softness of
rainbow
border
region
0.00 to 100.00
4 GRD Soft Softness of
gradation
border
region
0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Angle Rotation
angle of
pattern
–8.00 to +8.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation
speed of
pattern
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
