252
Applying Special Effects (Edge Effects)
Chapter 11 DME Operations
When pattern number 304 is selected, the effect of
settings in the <Edge> group varies with the Size
setting.
To invert the regions of the cropping
In the Wipe Crop menu, press [Invert], turning it on.
Setting the aspect ratio of the wipe crop
pattern (Aspect)
1
In the Wipe Crop menu, press [Aspect], turning it on.
2
Set the following parameter.
a) When set to a negative value, the image is stretched vertically, to
become taller.
When set to a positive value, the image is stretched horizontally, to
become wider.
Rotating the wipe crop pattern (Rotation)
1
In the <Rotation> group of the Wipe Crop menu,
select one of the following.
Angle: Incline the pattern through a fixed angle.
Speed: Rotate the pattern at a fixed speed.
2
Depending on the selection in step 1, set the following
parameter.
When Angle is selected
a) –1.00 represents a whole turn counterclockwise, and +1.00
represents a whole turn clockwise. 0.00 is the original state.
When Speed is selected
a) –100.00 represents a speed of four whole turns counterclockwise per
second, and +100.00 represents a speed of four whole turns
clockwise per second. 0.00 is the stationary state.
Applying modulation to the wipe crop
pattern (Modulation)
1
In the <Modulation> group of the Wipe Crop menu,
select one of the following.
H (horizontal modulation): Modulate the pattern to
apply waving in the horizontal direction.
V (vertical modulation): Modulate the pattern to
apply waving in the vertical direction.
2
Set the following parameters.
Replicating the wipe crop pattern
(Multiplication)
1
In the Wipe Crop menu, press [Multi], turning it on.
2
Set the following parameters.
a) See the replication patterns (page 132).
Modifying the wipe crop pattern edge
You can apply a border to the wipe crop pattern, or soften
the boundary.
1
In the <Edge> group of the Wipe Crop menu, select
one of the following.
Border: border
Soft: soft edge
Soft Border: soft border
2
Depending on the selection in step 1, set the following
parameters.
When Border is selected
Notes
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio –100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Angle of
pattern
rotation
–8.00 to +8.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate
of pattern
–100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Amplitude Amplitude of
modulation
0.00 to 100.00
2 Frequency Frequency of
modulation
0.00 to 100.00
3 Speed Speed of
waves
–100.00 to +100.00
Knob Parameter Adjustment Setting values
1 H Multi Number of
repetitions of
pattern
horizontally
1 to 63
2 V Multi Number of
repetitions of
pattern
vertically
1 to 63
3 Invert Type Replication
layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
To Next Page
