Sony MVS-7000X - Page 268

268
Applying Special Effects (Nonlinear Effect Settings)
Chapter 11 DME Operations
When Radial mode is selected
a) Set when Lock is on.
b) Set when Lock is off.
c) Setting for SD 4:3, SD 16:9
d) Setting for HD 4:3, HD 16:9
When Angular mode is selected
a) Set when Lock is on.
b) Set when Lock is off.
When Both mode is selected
a) Set when Lock is on.
b) Set when Lock is off.
c) Setting for SD 4:3, SD 16:9
d) Setting for HD 4:3, HD 16:9
When Shape mode is selected
Knob Parameter Adjustment Setting values
1Amp RRipple
amplitude
along radius
0.00 to 100.00
2 Freq R Ripple
frequency
along radius
0.00 to 100.00
3 Offset R
a)
Direction
along radius
in which to
offset ripple
phase and
amount of
movement
–8.000 to +8.000
c)
–32.000 to
+32.000
d)
4 Speed R
b)
Ripple
direction
along radius
and speed
–100.00 to +100.00
5Amp ARipple
amplitude
along
periphery
0.00 to 100.00
Knob Parameter Adjustment Setting values
1Amp ARipple
amplitude
along
periphery
0.00 to 100.00
2 Freq A Ripple
frequency
along
periphery
0.00 to 100.00
3 Offset A
a)
Direction
along
periphery in
which to
offset ripple
phase and
amount of
movement
–8.000 to +8.000
4 Speed A
b)
Ripple
direction
along
periphery
and speed
–100.00 to +100.00
5Amp RRipple
amplitude
along radius
0.00 to 100.00
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 Amp R Ripple
amplitude
along radius
0.00 to 100.00
2 Freq R Ripple
frequency
along radius
0.00 to 100.00
3Offset R
a)
Direction
along radius
in which to
offset ripple
phase and
amount of
movement
–8.000 to +8.000
c)
–32.000 to
+32.000
d)
4 Speed R
b)
Ripple
direction
along radius
and speed
–100.00 to +100.00
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Amp A Ripple
amplitude
along
periphery
0.00 to 100.00
2 Freq A Ripple
frequency
along
periphery
0.00 to 100.00
3Offset A
a)
Direction
along
periphery in
which to
offset ripple
phase and
amount of
movement
–8.000 to +8.000
4 Speed A
b)
Ripple
direction
along
periphery
and speed
–100.00 to +100.00
Parameter group [1/2]
Knob Parameter Adjustment Setting values
1 Amp R Ripple
amplitude
0.00 to 100.00
2 Freq R Ripple
frequency
0.00 to 100.00
