269
Applying Special Effects (Nonlinear Effect Settings)
Chapter 11 DME Operations
a) Set when Lock is on.
b) Set when Lock is off.
c) Setting for SD 4:3, SD 16:9
d) Setting for HD 4:3, HD 16:9
e) 1 (Circle): Circle
2 (Rectangle): Rectangle
3 (Star): Star
4 (Heart): Heart
To limit the direction in which modulation is
applied
By pressing [Plus Only], turning it on, you can limit the
direction in which modulation is applied (the direction in
which the image expands) to the plus direction only.
To set the ripple center point
1 Press [Position], turning it on.
2 Set the following parameters, depending on the
selected modulation mode.
When Shape is selected
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
When other than Shape is selected
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
To limit the ripple range
1 Press [Range], turning it on.
2 Set the following parameters.
When Radial or Shape mode is selected
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
When Angular mode is selected
When Both mode is selected
3 Offset R
a)
Direction in
which to
offset ripple
phase and
amount of
movement
–8.000 to +8.000
c)
–32.000 to
+32.000
d)
4 Speed R
b)
Ripple
direction and
speed
–100.00 to +100.00
5 Shape Ripple shape 1 to 4
e)
Parameter group [2/2]
Knob Parameter Adjustment Setting values
1 Aspect Ripple
aspect ratio
–100.00 to +100.00
2 Angle Ripple angle –8.000 to +8.000
Knob Parameter Adjustment Setting values
1 H Ripple center
point in
horizontal
direction
–5.000 to +5.000
a)
–20.000 to
+20.000
b)
2 V Ripple center
point in
vertical
direction
–3.000 to +3.000
a)
–12.000 to
+12.000
b)
Parameter group [1/2]
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 H Ripple center
point in
horizontal
direction
–8.000 to +8.000
a)
–32.000 to
+32.000
b)
2 V Ripple center
point in
vertical
direction
–6.000 to +6.000
a)
–18.000 to
+18.000
b)
Knob Parameter Adjustment Setting values
1 Size R Amount of
ripple
modulation
along radius
0.00 to 100.00
2 Offset R Center of
modulation
range along
radius
–8.000 to +8.000
a)
–32.000 to
+32.000
b)
Knob Parameter Adjustment Setting values
1 Size A Amount of
ripple
modulation
along
periphery
0.00 to 100.00
2 Offset A Center of
modulation
range along
periphery
–8.000 to +8.000
Knob Parameter Adjustment Setting values
1 Size R Amount of
ripple
modulation
along radius
0.00 to 100.00
2 Offset R Center of
modulation
range along
radius
–8.000 to
+8.000
a)
–32.000 to
+32.000
b)
