Serial Port Settings (Serial Port Assign Menu)
Chapter 22 DCU Setup (DCU)
10 Press [Set].
11 If required, repeat steps 4 to 10, to set other items.
To enable or disable the loop and recue functions
Press the [Loop] and [Recue] buttons, respectively.
Loop: Replay the recalled file in a continuous loop.
Recue: After playing the recalled file, recue to the
beginning and then stop.
Making detailed settings for an Extended
VTR
1 In the DCU >Serial Port Assign menu, select the
setting target (DCU1 or DCU2) from the <DCU
Select> group.
2 Using any of the following methods, select the serial
port connected to the Extended VTR for which you
want to make the settings.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
a) The range of setting values depends on the DCU port setting. (When
the MKS-2700 is connected, select 2 for the slot and a value in the
range 1 to 6 for the port.)
3 Press [Port Setting].
The DCU >Serial Port Assign >Extended VTR Setting
menu appears.
At the top of the status area, the relevant serial port,
slot number, protocol, serial port name, and SCU
number appear. In the lower part of the status area, the
response speed settings appear.
4 Using any of the following methods, specify the
command to which the response speed setting applies.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
a) 1. Maximum Open Delay: maximum time required to open a file
2. Maximum Cueup Delay: maximum time required to cue up a file
3. Play After Cueup Delay: maximum delay time from the cued-up
state to begin playback
4. Stop Delay: delay time from issuing the stop command until
actually stopping
5 Turn the knob to set the response speed of the
Extended VTR.
6 Press [Set].
7 Repeat steps 4 to 6 as required to make the settings for
other items.
Knob Parameter Adjustment Setting values
1 Port No Serial port
number
1 and
upwards
a)
Knob Parameter Adjustment Setting values
1 Item No Item selection 1 to 4
a)
Knob Parameter Adjustment Setting values
2 Setting Response speed
setting
0 to 255
