Macro File Editing Rules
Appendix (Volume 2)
WipeSnapshot ME? ME1 to ME4, PP Control blocks on the applicable bank
Register? 1 to 10 Applicable register number
DMEWipeSnapshot ME? ME1 to ME4, PP Control blocks on the applicable bank
Register? 1 to 10 Applicable register number
TimelineRecall Region? ME1 to ME4, PP, User1 to
User8, DME1 to DME8,
PBus, Device1 to
Device12, GPI
Applicable region
Register? 1 to 399 Applicable register number
TimelineRun Region? ME1 to ME4, PP, User1 to
User8, DME1 to DME8,
PBus, Device1 to
Device12, GPI, Current (a)
Applicable region
(a): Mode in which operation takes
place in the region currently specified
in the numeric keypad control block
TimelineRewind Region? ME1 to ME4, PP, User1 to
User8, DME1 to DME8,
PBus, Device1 to
Device12, GPI, Current (a)
Applicable region
(a): Mode in which operation takes
place in the region currently specified
in the numeric keypad control block
TimelineFF Region? ME1 to ME4, PP, User1 to
User8, DME1 to DME8,
PBus, Device1 to
Device12, GPI, Current (a)
Applicable region
(a): Mode in which operation takes
place in the region currently specified
in the numeric keypad control block
Shotbox Register? 1 to 99 Applicable register number
Pause Time? 0 to 999 Time for which macro is paused
(number of frames)
StartTc Device? 1 to 12,
FrameMemory1Clip to
FrameMemory8Clip
Applicable device
MasterSnapshot Register? 1 to 99 Applicable register number
MasterTimelineRecall Register? 1 to 99 Applicable register number
RouterXpt DestinationButton? 1 to 128 Router cross-point button
Source? 1 to 1024 Router source number
Level? 1 to 8 Router level selection
PatternLimit ME? ME1 to ME4, PP Control blocks on the applicable bank
Status? ToOn (a),
ToOff (b),
Any (c)
Pattern limit status
(a): Pattern limit applies
(b): Pattern limit does not apply
(c): The pattern limit status always
changes
TransitionType ME? ME1 to ME4, PP Control blocks on the applicable bank
TransitionType? Mix, NAM, SuperMix,
PresetColorMix, Wipe,
DMEWipe, FM1&2Clip,
FM3&4Clip, FM5&6Clip,
FM7&8Clip
Transition type
KeyTransitionType ME? ME1 to ME4, PP Control blocks on the applicable bank
Key? Key1 to Key8 Key of the applicable independent key
transition control block
Direction? On (a),
Off (b),
Any (c)
Independent key transition execution
mode
(a): Key is inserted
(b): Key is deleted
(c): Transition is always executed
KeyTransitionType? Mix, Wipe, DMEWipe, Cut Transition type of the independent key
transition control block
Symbol Parameter name Arguments Description
