Stryker GoBed II - Head End Cover with Nurse Call and Pendant Port, Without Scale

www.stryker.com 280C-009-002 REV B 1-101
Return To Table of Contents
English
Head End Cover with Nurse Call and Pendant Port, without Scale
OL280101 Rev D (Reference Only)
8
2
1
5
7
4
3
Item Part No. Part Name Qty.
1 28-0678P Head End Cover 1
2 28-0285P Nurse Call Mounting Plate 1
3 QDF20-0121 GENIII Interface 1
4 QDF5097 GENIII Connector Support 1
5 QDF8047 Electronic Board Jumper 2
7 VV83A9G12 Pan Head Tapping Screw 12
8 QDF2155 Steel Cable Clamp 1
Head End
Connector Pin
J5 2-3
J6 2-3
