HEAD END LIFT MOTOR REPLACEMENT (CONTINUED)
12. To adjust the limits of the new motor, proceed as follows:
A. Ensure the motor cable is connected to the control board and plug the power cord into the wall receptacle.
B. Press the bed down control until the motor stops. This will be the lower limit of the motor.
C. Attach the molded nut support on the motor to the lift lever arms.
D. With the alignment fixtures still in place, raise and lower the bed completely to ensure the lower limit is
properly adjusted.
13. Test the Bed Up and Bed Down functions for proper operation before returning the bed to service.
FOOT END LIFT MOTOR REPLACEMENT
Note
In order to maintain the adjustment of the low position when replacing a lift motor, a special tool kit must be used. The kit
includes alignment fixtures. To obtain this kit, contact our Customer Service department and order part number KR0154.
Tools Required:
• Tool Kit KR0154
• Cutting Pliers
• #2 Phillips Screwdriver
• Small Regular Screwdriver
• 1/2” Combination Wrench
• Bungee Cord (or equivalent)
Note
When raising or lowering any of the litter sections, ensure that all siderails are in the highest position. Unless otherwise
indicated, refer to Figure 10, page 1-44, for reference for this procedure.
1. Install the alignment fixtures (KR0154) on both sides of the brake mechanism on the base frame, under the lower
fixed frame.
2. Lower the bed, until the lower fixed frame is completely supported by the U-shaped pieces of the fixture (see Figure
9, page 1-44).
3. Remove the mattress and the plastic litter cover (if equipped) from the foot section metal frame.
4. Raise the fowler section to about 45°, and raise the thigh section to the highest position.
5. Fold the foot section back toward the head end of the bed. Secure it using a bungee cord.
6. Unplug the power cord from the wall receptacle.
7. Using a #2 Phillips screwdriver, remove the four screws holding the frame cover plate.
8. Using cutting pliers, cut the cable ties holding the defective lift motor power cord to the bed frame. Unplug the motor
connector.
9. Using a 1/2¨ combination wrench, remove the two bolts (D), two washers (C) and two spacers (B) holding the
molded nut support to the elevation lever arm.
10. Using a #2 Phillips screwdriver, remove the two screws holding the motor support cover to the lift lever arm and
remove it.
11. Remove the two pivot pins (H) holding the motor (A) to the support. To ease the removal of the pins, insert a small
regular screwdriver into the opening at the end of the motor and push out the pins.
12. Remove the defective motor by passing it under the bed frame.
13. Using a #2 Phillips screwdriver, remove the two screws (F) holding the plastic screw cover (J) to the motor. Remove
the plastic screw cover and install it on the new actuator.
