Stryker GoBed II - Fixed Three Stage I.V. Pole, Foldable - FA64170

www.stryker.com 280C-009-002 REV B 1-155
Return To Table of Contents
English
Fixed Three Stage I.V. Pole, Foldable - FA64170
L64-099 Rev D (Reference Only)
7
9
3
11
1
6
5
11
10
2
4
8
15
9
13
14
16
12
Item Part No. Part Name Qty.
1 64-0734C I.V. Pole Support 1
2 64-1351 I.V. Pole Stopper 1
3 QDF64-0614 Three Stage I.V. Pole 1
4 64-1215P Storage Bracket Plate 1
5 QE14399-T Label - Manufacturer 1
6 QE71-0246-T Label - Warning 1
7 VB15A1O24-S Hex Bolt 1
8 VB15A1O44 Hex Bolt 1
9 VE30A1O Nylon Hex Locknut 3
10 VV83A9G16 Pan Head Tapping Screw 2
11 VW10A10 Washer 2
12 90-1854P Roller Bumper Support 2
13 QDF2094 Roller Bumper 2
14 VB15A1N24 Hex Bolt 4
15 VB15A1O60 Hex Bolt 2
16 VE30A1N Nylon Hex Locknut 4
