SCALE SYSTEM LCD DISPLAY REPLACEMENT (OPTIONAL)
Tools Required:
• Small Regular Screwdriver
• #2 Phillips Screwdriver
Note
Unless otherwise indicated, refer to Figure 5 (page 1-33) for this procedure.
Procedure:
1. Raise the bed to the highest position and apply the brakes.
2. Unplug the power cord from the wall receptacle.
3. Using a small regular screwdriver, lift and remove the five round self-adhesive screw-covers (B) located on the foot
board cover as well as the self-sticking membrane (A) of the foot board control panel to expose the screws holding
the cover to the foot board. Use caution when inserting the screwdriver under the membrane to avoid scratching
the plastic cover.
Note
Do not reuse the self-adhesive parts due to their adhesive coating considerably losing its effectiveness once they are
removed. Replace them with new parts.
4. Properly ground yourself (see the “Static Protection Procedure”, page 1-13).
5. Using a #2 Phillips screwdriver, remove the seven screws (C) holding the cover to the foot board and remove the
cover after having removed the cables connected to it. Note the cable positions in order to replace them properly.
6. Using a small regular screwdriver, push aside the clips (D) and remove the LCD display (E) after having disconnected
its cable.
7. Reverse the above steps to install the new LCD display.
8. Test the LCD display for proper operation before replacing the foot board cover and returning the bed to service.
