Sun Microsystems Ultra 20 M2 - FIGURE 5-37 Removing the Nine Motherboard Screws

5-54 Sun Ultra 20 M2 Workstation Service Manual • January 2007
6. Remove the nine Phillips screws that fasten the motherboard to the chassis (see
FIGURE 5-37).
FIGURE 5-37 Removing the Nine Motherboard Screws
Note – Do not remove the four screws that secure the CPU heatsink/fan assembly
mounting to the motherboard.
