1-2 Sun Ultra 20 M2 Workstation Service Manual • January 2007
1.1 Front Panel
FIGURE 1-1 illustrates the front panel of the Sun Ultra 20 M2 Workstation. TABLE 1-1
lists the components called out in the figure.
FIGURE 1-1 Front Panel Components
TABLE 1-1 Front Panel Components
Label Button/LED/Port Label Button/LED/port
1 Power button 4 Two USB 2.0 ports
2 Power LED 5 Microphone-in jack
3 Two 1394 ports 6 Headphone-out jack
