Servicing FRUs 133
Caution – Be careful not to allow the processor socket cover to fall into the
processor socket as this could result in damage to the socket.
e. Install a processor into the socket from which you removed the processor
socket cover.
For instructions for installing a processor, see “Install a Processor” on page 112.
f. Repeat Step a through Step e above to remove the second processor socket
cover from the replacement motherboard and install the second processor.
14. Install the processor socket covers on the faulty motherboard.
Caution – The processor socket covers must be installed on the faulty motherboard;
otherwise, damage might result to the processor sockets during handling and
shipping.
Caution – Be careful not to allow the processor socket cover to fall into the
processor socket as this could result in damage to the socket.
a. Open one of the processor ILM assemblies on the faulty motherboard
[Frames 1 and 2].
