OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
3.10.17 Loading Operation
Digging with bucket and arm, the operation is
the same as that of the backhoe.
Swing upper frame when is lifting boom.
When bucket reach to top of the truck, stop to
swing and boom lifting, open arm and bucket
to unload.
After the unloading is completed, swing upper
frame, properly closed bucket and arm.
Note：The excavator can loading
swing with 90°and 180°，in order to
improve operation efficiency, try your
best swing with 90°.
