OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
3.6 Seat
Seat adjustment specification
(1) headrest adjustment: imposed the upward force
the headrest can make the head pillow to proper
height.
(2) backrest adjustment: lightly back seat backrest t,
upward rotate handle, push backrest to the proper
position with the back, loosen the handle, the backrest
can be locked.
(3)damping adjustment: rotate handwheel, according
to road conditions and driver weight to preset force to
the needed numerical value. Do not adjust white
pointers to the position which is less than 40 to more
than 130.
(4) the level adjustment: upward move rod which is
under the seat, the seat forward (back) to the proper
position, loosen the tie rod, the seat can be locked.
