5.2.5 Electric elements table
.O
NAME
N.O
NAME
1
Throttle servo-motor
27
Lighter
2
Safety relay
28
GPS
3
Flame out control relay
29
Preheat relay
4
Fuel valve relay
30
Controller
5
Starter
31
Electronic oil pump
6
Head light relay
32
Radio
7
Generator
33
Washer assy.
8
Water temperature sensor
34
Wiper controller
9
Air filter indicator
35
Horn
10
Overheating alarm switch
36
Cigar lighter
11
Engine oil pressure alarm switch
37
GPS monitor system
12
Solenoid power switch
38
Electric control case assy.
13
Throttle driving plate
39
Connecting terminal
14
Work lamp
40
Single core plug
15
Oil level sensor
41
1s delayed module
16
Micro-active switch
42
15s delayed module
17
Press button switch end mounting
frame
43
Standby relay 1
18
Press button switch mid-frame
44
Standby relay 2
19
Auto-idle switch
45
Standby relay 3
20
Quick selection switch
46
Horn relay
21
Front light switch
47
Fuel gasoline pump
22
Work light switch
48
Core 18 connector
23
Alarm light switch
49
Core 22 connector
24
Wiper switch
50
Warning lamp
25
Washer switch
51
Accumulator 100Ah
26
Press button switch cover
52
Warning lamp
