SUNWARD SWE50E - Every 250 Hours

OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
162
4.5.6 Every 250 hours
Carry out 50 hours service at the same
time.
4.5.6.1 Checking swing redactor gear oil
level
 Stop the machine at level ground.
 Shut auto-idling switch to run the engine
unloaded at low temperature for 5
minutes.
【Important】
 Stopping the engine improperly may
damage turbocharger.
 Set start key to OFF position, stop the
engine, remove the key from starting
lock, set safety lock lever to LOCK
position.
Note
 After completing work, the gear oil
temperature might be very high, wait
for temperature to cool down.
 Pull out dipstick of swing redactor, wipe
off oil trace, reinsert it and pull out
again, the oil mark should be between
the two scales.
 If necessary, remove oil fill cap to add
gear lubricating oil. Check oil level
again.
