SUNWARD SWE50E - SWE100 E Machine Specification; Machine Specification

OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
214
5.5 SWE100E Machine specification
5.5.1 Machine specification
Machine specification
SWE100E
Operation weight
9500 kg
Standard bucket capacity
0.4 m3
Track shoe width
450 mm
Power plant
Engine model
V3800DI-T-E3B-CBH2-5
Type
Direct injection, water cooled, 4
strokes
Bore ｘstoke
4
Displacement
3.769 L
Rated power/revs
60.7kW/2200rpm
Fuel tank capacity
145 L
Hydraulic system
Main pump
2 variable plunger pumps
Work pressure setting
30 MPa
Front work
equipment(force increase state)
30 Mpa
Travel
30 Mpa
Slewing
24 Mpa
pilot pressure setting
3.9 Mpa
Hydraulic oil tank capacity
120 L
Performance specification
Slewing speed
10.8 rpm
Travel speed
4.5/2.7 km/h
Max traction
70 kN
Max grade ability
35°
Bucket max digging force
64.5 kN
Arm max digging force
43 kN
