OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
2.1 Transportation
2.1.1 General transportation instruction
Before using trailer to transport machine, contact local traffic department to confirm relevant regulations,
make sure that machine’s overall length, width, height and weight are within allowed spec.
If there are any dimensions out of spec, obtain special permission from relevant government agencies or
dismantle the machine into smaller unit to transport.
Select proper transportation tools according to machine’s weight, length, width and height.
Survey the traffic condition for transportation in advance, e.g. road condition and width, height of
bridges and tunnels as well as the limits of weight and traffic regulation etc.
Please note:
Transportation weight and dimension of the machine may change with different
configuration of the front
Device and accessories.
2.1.2 Transportation specification
Transportation parameters are as following picture:
The specific dimension in transport parameter and outline dimensional drawing are shown in
section 5(Technical specification).
