OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
2.1.4 Loading
Note
Load the machine only on firm, level
ground and keep a safe distance with
the road shoulder.
Chock the machine to prevent the
machine movement during loading
process.
The ramp for loading must have enough
strength and width with an maximum
slope of 15°, be sure both side of the
ramp is at equal level so that machine
could travel safely.
Loading operation
Switch off idle speed, set engine speed to low
speed by means of fuel control knob.
Set travel speed selector to low speed position.
Machine direction：When loading, if machine
is equipped with working device, keep the
working device at the front of the machine and
travel forward. If no working device, travel in
reverse to load the machine.
Align the direction of the machine with the
ramp： be sure the center line of the machine
track matches that of the ramp and travel
slowly.
Lower the working equipment as much as
possible without causing any interference on
the machine. When traveling on slope, operate
only the travel lever; never operate the other
lever or pedal.
When the machine travels over the rear wheels
of trailer, travel the machine slowly so that the
smooth change of machine position (from
grading to level) is possible. pay attention not
to make working equipment hit trailer.
When the machine travels to the middle of the
trailer, slew the upper-structure 180°making
the working equipment face backside of the
machine.
To Next Page
