SUNWARD SWE50E - SWE80 E9 Machine Specification; Machine Specification

OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
207
5.4 SWE80E9 Machine specification
5.4.1 Machine specification
Machine specification
SWE80E9
Operation weight
7680 kg
Standard bucket capacity
0.3 m3
Track shoe width
450 mm
Power plant
Engine model
4TNV98-ZCSSU
Type
Direct injection, water cooled, 4
strokes
Bore ｘstoke
4
Displacement
3.319 L
Rated power/revs
44kW/2200rpm
Fuel tank capacity
145 L
Hydraulic system
Main pump
1 variable plunger pump
Flow capacity
168L/min
Work pressure setting
30 MPa
Front work
equipment(force increase state)
30 MPa
Travel
30 MPa
Slewing
24 MPa
pilot pressure setting
3.5 Mpa
Hydraulic oil tank capacity
95 L
Performance specification
Slewing speed
11 rpm
Travel speed
4.7/2.8 km/h
Max traction
70 kN
Max grade ability
35°
Bucket max digging force
58 kN
Arm max digging force
40 kN
