SUNWARD SWE50E - SWE60 E Machine Specification; Machine Specification

OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
193
5.2 SWE60E Machine specification
5.2.1 Machine specification
Machine specification
SWE60E
Operation weight
6000 kg
Standard bucket capacity
0.2 m3
Track shoe width
400mm
Power plant
Engine model
4TNV94L-BVSU
Type
Direct injection, water cooled, 4
strokes
Bore ｘstoke
4
Displacement
3.054 L
Rated power/revs
36.2kW/2100rpm
Fuel tank capacity
113 L
Fuel capacity
Main pump
2 variable plunger pumps, 1 gear
pump
Flow capacity
2×59+42L/min
Work pressure setting
24/24/21 MPa
Front work
equipment(force increase state)
24 Mpa
Travel
24 Mpa
Slewing
21 Mpa
pilot pressure setting
3.9 Mpa
Hydraulic oil tank capacity
96 L
Performance specification
Slewing speed
9.4 rpm
Travel speed
4.74/2.75 km/h
Max traction
42.1 kN
Max grade ability
35°
Bucket max digging force
46.8 kN
Arm max digging force
31.1 kN
