SUNWARD SWE50E - SWE50 E Technical Specification; Machine Specification

OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
186
5.1 SWE50E Technical specification
5.1.1 Machine specification
Machine specification
SWE50E
Operation weight
5100 kg
Standard bucket capacity
0.18 m3
Track shoe width
400mm
Power plant
Engine model
4TNV88-BSSU
Type
Direct injection, water cooled, 4
strokes
Bore ｘstoke
4
Displacement
2.19 L
Rated power/revs
25.8/2200 kW/rpm
Fuel tank capacity
113 L
Fuel capacity
Main pump
2 variable plunger pumps, 1 gear
pump
Flow capacity
2×45+37L/min
Work pressure setting
24.5/24.5/21 MPa
Front work
equipment(force increase state)
24.5 Mpa
Travel
24.5 Mpa
Slewing
21 Mpa
pilot pressure setting
3.9 Mpa
Hydraulic oil tank capacity
96 L
Performance specification
Slewing speed
10.1 rpm
Travel speed
4.7/2.4 km/h
Max traction
37.1kN
Max grade ability
30°
Bucket max digging force
33.7 kN
Arm max digging force
27.8 kN
