SUNWARD SWE50E - SWE70 E Machine Specification; Machine Specification

OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
200
5.3 SWE70E Machine specification
5.3.1 Machine specification
Machine specification
SWE70E
Operation weight
6560 kg
Standard bucket capacity
0.26 m3
Track shoe width
400mm
Power plant
Engine model
4TNV98-ZCSSU
Type
Direct injection, water cooled, 4
strokes
Bore ｘstoke
4
Displacement
3.319 L
Rated power/revs
44kW/2200rpm
Fuel tank capacity
118 L
Fuel capacity
Main pump
2 variable plunger pumps, 1 gear
pump
Flow capacity
2×59+42L/min
Work pressure setting
24/24/21 MPa
Front work
equipment(force increase state)
24 Mpa
Travel
24 Mpa
Slewing
21 Mpa
pilot pressure setting
3.9 Mpa
Hydraulic oil tank capacity
96 L
Performance specification
Slewing speed
9 rpm
Travel speed
4/2.3 km/h
Max traction
56.7 kN
Max grade ability
35°
Bucket max digging force
49.4 kN
Arm max digging force
31 kN
