SUNWARD SWE50E - Work Specification

OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
188
5.1.3 Work specification
unit: mm
Machine specification
SWE50E
A、
Max digging height
5230
B、
Max dumping height
3720
C、
Max digging depth
3600
D、
Max vertical digging depth
2840
E、
Max digging radius
5940
F、
Max reach at ground level
5820
G、
Max. lifting height of push plate
300
H、
Max. digging depth of push plate
275
G、
Minimum swing radius
2650
