SUNWARD SWE50E - Work Specification

OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
195
5.2.3 Work specification
unit: mm
Machine specification
SWE60E
A、
Max digging height
5620
B、
Max dumping height
4010
C、
Max digging depth
3700
D、
Max vertical digging depth
2840
E、
Max digging radius
6125
F、
Max reach at ground level
5985
G、
Max. lifting height of push plate
445
H、
Max. digging depth of push plate
340
G、
Minimum swing radius
2480
