OPERATION & MAINTENANCE MANUAL SWE50E/SWE60E/SWE70E/SWE80E9/SWE100
167
4.5.7.2 Lubricate swing mechanism
 Stop the machine at level ground, lower
the bucket to ground.
 Stop auto-idle switch, run the engine
unloaded at low speed for 5 minutes.
【Important】
 Stopping the engine improperly may
damage turbocharger.
 Set start key to OFF position, stop the engine,
remove the key from starting lock, set safety
lock lever to LOCK position.
 Loosen 2 bolts of grease fill port cover located
on front part of turret. Then remove grease fill
port cover (1).
 Check that grease height in the position where
pinion passes by should be at least 14mm
(0.6in), and free of pollution; add 0.5kg
lubricate grease to reach standard height if
necessary.
 Check the color of the grease, in case of white,
change it.
 Drain port locates around central swing joint
under lower carriage frame.
