13.5.3 Presentation of STIPA results
The STIPA results are grouped in one window
with the appropriate division into areas, sources
and points for the selected project. When
opening a project from the BA Assistant
application or creating a "Simple project" project
in SvanPC++, the STIPA window will open
automatically. When opening individual SVL
files, the results pane is accessed via the "STI"
button on the toolbar.
In case of "Simple project" projects, this window
can also be opened via the "Add available panel"
tab and selecting "STI".
STIPA results by default appear for areas, sources and points. Each point on the view is a button which, when
pressed, shows measurement results for a given point.
Each measurement has a "checkbox" which can be used to enable / disable a given measurement - in this
situation the STIPA results for the point and higher groups will be automatically recalculated after the
measurement is turned on / off.
Each point after the expansion has background noise results at the end of the measurement list.
