SV 977D User Manual - Appendixes
B.3. DESCRIPTION OF CYCLICAL RESULTS BLOCKS (SUMMARY RESULTS)
Table B.39. Block of counters
Word
number
Name
Comment
0
0nn59h
59h = block identifier
0nnh = block length in words
1..2
CycleNo
measurement cycle number
…
reserved
Table B.40. Block of Summary Results
Word
number
Name
Comment
0
0nn07h
07h = block identifier
0nnh = block length in words
1
00pxxh
p = number of profiles, 0xxh = profile bit mask (the bit mask indicates
for which profiles the results are available)
2..
Profile[1]
internal block with identifier 08h with the results for the first profile
whose bitmask is set - see
Table B.41
...
...
...
...
Profile[p]
internal block with identifier 08h with the results for the last profile
whose bitmask is set - see
Table B.41
...
MeterTableRes
Internal block with the identifier 0Ch with the results of "Meter Table"
- see
0
…
reserved
Table B.41. Results for one profile (block exists only inside the Summary results block – see
Table B.40)
Word
number
Name
Comment
0
0nn08h
08h = block identifier,
0nnh = block length in words
1..2
Time
for the results of the first profile:
– measurement time in seconds
for the results of the second profile:
– overload duration in seconds
for the results of the third profile:
– duration of excessive vibration in seconds
3
Peak
value of the "Peak" result in the format 0.01 dB
4
P–P/SEL
"P-P" value in 0.01 dB format for vibration measurement mode
or
"SEL" value in 0.01 dB format for sound measurement mode
5
Max
value of the "Max" result in the format 0.01 dB
6
Reserved/ Min
value reserved for vibration measurement mode
or
„Min" value in 0.01 dB format for sound measurement mode
7
Reserved/ Spl
value reserved for vibration measurement mode
or
„Spl" value in 0.01 dB format for sound measurement mode
