Svantek SV 977D User Manual

229
SV 977D User Manual - Appendixes
Word
number
Name
Comment
8
RMS/Leq
"RMS" value in 0.01 dB format for vibration measurement mode
or
"Leq" value in 0.01 dB format for sound measurement mode
9
Reserved/ Lden
value reserved for vibration measurement mode
or
„Lden" value in 0.01 dB format for sound measurement mode
10
Reserved
11
Reserved/ LTeq
value reserved for vibration measurement mode
or
„LTeq" value in 0.01 dB format for sound measurement mode
12
Reserved/ LR1
value reserved for vibration measurement mode
or
„LR1" value in 0.01 dB format for sound measurement mode
13
Reserved/ LR1
value reserved for vibration measurement mode
or
„LR2" value in 0.01 dB format for sound measurement mode
14
reserved
15
Underrange
underrange flag:
0 – signal level values are equal to or greater than the declared
lower range of measured values,
1 – signal level values are less than the declared lower range of
measured values
16
ResultsFlags
bit 1 (overload flag):
0 – no overload,
1 – overload occurred
bits 5..3 (Lden result type - only for sound measurement mode):
000 – no Lden result
001 – Ld result
010 – Le result
011 – Lde result
100 – Ln result
101 – Lnd result
110 – Len result
111 – Lden result
remaining bits are reserved
17
Reserved/ EX
value reserved for the vibration measurement mode
or
EX result value in the format 0.01 dB for the sound measurement
mode
18
Reserved/ SD
value reserved for the vibration measurement mode
or
SD result value in the format 0.01 dB for the sound measurement
mode
…
reserved
