SV 977D User Manual - Appendixes
Table B.42. "Meter Table" results (this block appears only inside the main result block – see Table B.40)
Word
number
Name
Comment
0
0nn0Ch
0Ch = block identifier
0nnh = block length in words
1
LCpeak
value of the LCpeak result in the format 0.01 dB
2
LCeq
value of the LCeq result in the format 0.01 dB
3
LAFmax1s
value of the LAFmax1s result in the format 0.01 dB
4
LAeq
value of the LAeq result in the format 0.01 dB
5
LAFeq
value of the LAFeq result in the format 0.01 dB
6
LAIeq
value of the LAIeq result in the format 0.01 dB
…
reserved
Table B.43. Statistical analysis results (only for sound measurement mode)
Word
number
Name
Comment
0
0nn17h
17h = block identifier
0nnh = block length in words
1
00pxxh
p = number of profiles, 0xxh = profile bit mask (bit mask informs about
which profile results are available)
2
N
number of statistical levels
3
nn[1]
first level number (common to all profiles)
4
Lnn[1][1]
first level Lnn value for the first profile whose bit mask is set
...
...
...
...
Lnn[1][p]
first level Lnn value for the last profile whose bit mask is set
...
nn[i]
number of the next level (common for all profiles):
i = 2..N
...
Lnn[i][1]
next level Lnn value for the first profile whose bit mask is set
...
...
...
...
Lnn[i][p]
next level Lnn value for the last profile whose bit mask is set
…
reserved
Table B.44. RPM measurement results
Word
number
Name
Comment
0
0nn1Fh
1Fh = block identifier
0nnh = block length in words
1..2
ROT
lower and higher word of the last value of RPM measured during the
measurement cycle; the value of the result is calculated according to
the formulas:
rps = 1/d – number of revolutions per second
rpm = 60/d – number of revolutions per minute
where:
d = m · 2
w
m = ((H & 7Fh)<<16) + ((L & 7FFFh)<<1)
w = ((H>>8) & 7Fh) – 87
L – lower word of the result
H – higher word of the result
& – bit product operator
